Krytox™ PFPE lubricants

Krytox™ PFPE lubricants for parts that can’t fail

Perfluoropolyether oils and PTFE-thickened greases that don’t burn, don’t react and outlast ordinary lubricants by years. Used where oxygen, heat, vacuum or aggressive chemicals rule out anything else.

NonflammableOxygen compatibleNo siliconeNSF H1 grades
−70 to 399 °Cservice range across the grades we supply
MIL-PRF-27617240 series aerospace and military greases
1500 seriesvacuum pump fluids for oxygen and reactive gas
0.5 oz–200 kgtubes and syringes up to drums

Choose by condition

Tell us temperature, speed, load and what the lubricant touches. These are the usual starting points.

ConditionGradesWhy
General bearings, valves, O-ringsGPL 205, 206, 207The workhorse greases. Higher last digit = heavier base oil for more heat and load
Above 300 °C continuousXHT-BDX, XHT-AC, GPL 407XHT grades are stabilized for extreme heat; GPL 407 is silica-thickened and non-melting to 399 °C
Slow, heavy or shock loadsGPL 214–217, GPL 294–297Molybdenum disulfide (21X) or extreme-pressure additives (29X)
Wet, humid or stored partsGPL 221–227, GPL 2E7Added corrosion inhibitor; 2E7 uses a non-nitrite anti-rust package
Oxygen and reactive gasNRT 8805 oil, NRT 8904, 8906, 8908The NRT series has passed BAM oxygen compatibility testing
Aircraft and military240AZ, 240AB, 240ACQualified to MIL-PRF-27617 Types I, II and III
Vacuum pumps1506, 1514, 1525, 1618, LVP greaseDistilled for low vapour pressure. See the vacuum cross-reference
Food processingGPL 202–207, GPL 225, GPL 105 oilNSF H1 registered for incidental food contact
Electrical contacts and switchesEG 2000, EG 3000White greases that won’t creep, oxidize or attack plastics
Corrugator and heated rollsCORR 226FG, 227FG, GPL 226, 227Anti-corrosion greases for steam-heated bearings

Reading a grade number

FamilyMeaningExamples
GPL 10XOils; viscosity rises with the last digitGPL 101–107
GPL 20XGreases made from the matching GPL oilGPL 201–207
GPL 21X / 22X / 29XAdds MoS2 / corrosion inhibitor / EP and anti-corrosionGPL 215, GPL 226, GPL 296
XHTTreated for stability above 300 °CXHT-AC, XHT-BDX, XHT-500
143 / 240Aerospace oils and greases with tighter volatility limits143AC, 240AC
1500 / 1600Vacuum pump and diffusion pump fluids1514, 1618

Cross-reference

Equivalents from the official Krytox™ crossover card. For anything else, send us the product name and we’ll match it.

You use nowKrytox™ equivalentType
Castrol Braycote 1724GPL 104PFPE lubricating oil
Fomblin Y 04GPL 102PFPE lubricating oil
Fomblin L-VAC 06/61506Vacuum pump fluid
Fomblin L-VAC 14/6, LOX 1201514Vacuum pump fluid
Fomblin L-VAC 25/61525Vacuum pump fluid
Fomblin H-VAC 18/81618Diffusion pump fluid

Brand names are trademarks of their owners and are listed for cross-reference only.

Where Krytox™ is used

From the applications our customers bring us most often:

Chemical and process

Seal lubricant and mechanical-seal barrier fluid in aggressive chemicals; pump seals, bearings and plug valves in chlorine service.

Oxygen and gas systems

Valve and O-ring lubricant in oxygen service; breathing apparatus and life-support systems.

Aerospace and instruments

Aircraft instrument and fuel-pump bearings, flotation fluids, electrical instrument oil, dielectric fluid.

Heat and ovens

Oven conveyor chains and bearings, wave-soldering equipment, paper machine force-feed oil systems.

Semiconductor and vacuum

Vacuum pump oils for semiconductor and printed-circuit-board plants; low-vapour-pressure greases.

Automotive and nuclear

Rubber weather-stripping, accessory bearings and EGR valves; long-life lubrication in nuclear plants.

Most ordered

1514

PFPE vacuum pump fluid for oxygen and reactive-gas service.

Quote
GPL 205

General-purpose PFPE/PTFE grease and the most common grade.

Quote
240AC

MIL-PRF-27617 Type III grease, −34 to 288 °C.

Quote
XHT-BDX

Extreme high-temperature bearing grease.

Quote
GPL 206

Heavier base oil than 205 for more heat and load.

Quote

Sizes

ProductFormats
Greases0.5, 2 and 8 oz tubes, syringes (some grades), 0.5 and 1 kg jars, 0.8 kg cartridges, 5 to 20 kg pails, drums
Oils0.5, 1 and 5 kg bottles, 10 and 20 kg pails, 200 kg drums

Not every grade comes in every size. Grades we don’t stock are ordered from Chemours; ask for the lead time.

Questions

Do bearings need cleaning before switching to Krytox™?

Yes. Remove all the old grease, oil and preservative. Hydrocarbon residue can carbonize at high temperature and shorten bearing life. We’ll send Chemours’ cleaning and repacking procedure.

Can Krytox™ be mixed with other greases?

It isn’t recommended. The mix only performs as well as the weaker grease, and hydrocarbon additives can stop the PFPE from wetting the bearing surface.

Is Krytox still a DuPont product?

Krytox™ has been made by Chemours since Chemours was spun off from DuPont in 2015. The grade names didn’t change, so order by the name on your current container.

How often do Krytox™ greases need relubrication?

It depends on the application. Corrugator bearings typically need it every one to three months; many other applications run months or years, and sealed bearings may never need it.
